Off-Grid
Easun undefined ISolar SMV IV 5600-48
View 1
View 2
View 3

Easun • ISolar SMV IV

ISolar SMV IV 5600-48

Region:China
Region shows where the seller or factory is located. Most ship globally, and all listed suppliers should be able to ship to your current location.
6kW
Nominal AC Power
93%
Max Efficiency
300 x 400
Dimensions (mm)
Size Your System Find Installer

Ideal Use Case

The Easun ISolar SMV IV 5600-48 is tailored for specific solar energy needs. This inverter is an excellent choice if you:

Have a 6.0 kW residential PV system
Have panels with uniform orientation and tilt
Focus on grid-tied operation without battery storage

Don’t guess your solar setup — calculate it first!

Take our Solar Quiz to get a personalized recommendation for panels, inverter, battery capacity, and system size — before you spend money on the wrong setup.

Run Technical Sizing

AC Output Data

Nominal AC Power6 kW
Max Efficiency93 %
Euro Efficiency0 %
Max AC Current100 A
Rated AC Current0 A
Number of Feed-in Phases0
THD (Total Harmonic Distortion)0 %

DC Input Data

MPP Voltage Range120~450 V
Max DC Voltage500 V
Min DC Voltage to Start0 V
Max DC Current120 A
Number of MPP Trackers1
DC Inputs0

Mechanical & Environmental Data

Dimensions (W x H x D)300 x 400 x 115 mm
Weight9.0 kg
DisplayLCD
InterfaceRS 232, RS 485, WLAN

Operating Conditions

Operating Temperature-10 ~ +50 ℃
Humidity5-95 %
Frequency50, 60 Hz
Power Consumption (Night)0 W

Similar Products

Product FAQ

What size solar array can the Easun ISolar SMV IV 5600-48 handle?

The Easun ISolar SMV IV 5600-48 has a nominal AC output of 6kW with a maximum efficiency of 93%. It is typically paired with a solar array of 7–8kW DC for optimal energy harvest.

Is the Easun ISolar SMV IV 5600-48 a hybrid inverter?

The Easun ISolar SMV IV 5600-48 is a off-grid inverter. To add battery storage, you would need a separate AC-coupled battery inverter or upgrade to a hybrid model.

Does the Easun ISolar SMV IV 5600-48 have WiFi monitoring?

Most Easun inverters come with or support optional WiFi/Ethernet dongles. This allows you to track your solar production and battery status via a mobile app or web portal in real-time.

How many MPPT trackers does the Easun ISolar SMV IV 5600-48 have?

This inverter features 1 independent MPPT tracker with a maximum DC input voltage of 500V. Multiple trackers allow panels on different roof faces or orientations to operate independently for maximum yield.
