FoxESS undefined T23-G3

FoxESS • T Series (G3) T3-T25-G3

T23-G3

Region:China
Region shows where the seller or factory is located. Most ship globally, and all listed suppliers should be able to ship to your current location.
34.5kW
Nominal AC Power
98.6%
Max Efficiency
370 x 480
Dimensions (mm)
Size Your System Find Installer

Ideal Use Case

The FoxESS T23-G3 is tailored for specific solar energy needs. This inverter is an excellent choice if you:

Manage a large 34.5 kW commercial or industrial solar array
Need 2 independent MPPT trackers for different roof orientations
Want maximum energy harvest (98.6% peak efficiency)
Focus on grid-tied operation without battery storage
Operate in extremely cold climates
Prefer silent, maintenance-free operation

Don’t guess your solar setup — calculate it first!

Take our Solar Quiz to get a personalized recommendation for panels, inverter, battery capacity, and system size — before you spend money on the wrong setup.

Run Technical Sizing

AC Output Data

Nominal AC Power34.5 kW
Max Efficiency98.6 %
Euro Efficiency97.8 %
Max AC Current36.7 A
Rated AC Current0 A
Number of Feed-in Phases0
THD (Total Harmonic Distortion)3 %

DC Input Data

MPP Voltage Range140~1000 V
Max DC Voltage1100 V
Rated DC Voltage600 V
Min DC Voltage to Start140 V
Max DC Current28 A
Number of MPP Trackers2
DC Inputs2

Mechanical & Environmental Data

Dimensions (W x H x D)370 x 480 x 183 mm
Weight17.0 kg
Protection ClassIP65
Cooling MethodNatural, Fan
DisplayLCD
InterfaceRS 485, WLAN

Operating Conditions

Operating Temperature-25 ~ +60 ℃
Humidity0-100 %
Frequency50, 60 Hz
Max Altitude3000 m
Transformer TypeTransformerless
Power Consumption (Night)3 W

Similar Products

Product FAQ

What size solar array can the FoxESS T23-G3 handle?

The FoxESS T23-G3 has a nominal AC output of 34.5kW with a maximum efficiency of 98.6%. It is typically paired with a solar array of 41–45kW DC for optimal energy harvest.

Does the FoxESS T23-G3 have WiFi monitoring?

Most FoxESS inverters come with or support optional WiFi/Ethernet dongles. This allows you to track your solar production and battery status via a mobile app or web portal in real-time.

How many MPPT trackers does the FoxESS T23-G3 have?

This inverter features 2 independent MPPT trackers with a maximum DC input voltage of 1100V. Multiple trackers allow panels on different roof faces or orientations to operate independently for maximum yield.
