On-Grid
GoodWe undefined GW25K-MT

GoodWe • GoodWe SMT Series

GW25K-MT

Region:Netherlands
Region shows where the seller or factory is located. Most ship globally, and all listed suppliers should be able to ship to your current location.
25kW
Nominal AC Power
98.7%
Max Efficiency
480 x 590
Dimensions (mm)
Size Your System Find Installer

Ideal Use Case

The GoodWe GW25K-MT is tailored for specific solar energy needs. This inverter is an excellent choice if you:

Operate a 25.0 kW commercial solar installation
Use three-phase grid connection
Need 3 independent MPPT trackers for different roof orientations
Want maximum energy harvest (98.7% peak efficiency)
Focus on grid-tied operation without battery storage
Operate in extremely cold climates

Don’t guess your solar setup — calculate it first!

Take our Solar Quiz to get a personalized recommendation for panels, inverter, battery capacity, and system size — before you spend money on the wrong setup.

Run Technical Sizing

AC Output Data

Nominal AC Power25 kW
Max Efficiency98.7 %
Euro Efficiency98.4 %
Max AC Current40 A
Rated AC Current0 A
Number of Feed-in Phases3
THD (Total Harmonic Distortion)3 %

DC Input Data

MPP Voltage Range200~950 V
Max DC Voltage1100 V
Min DC Voltage to Start180 V
Max DC Current0 A
Number of MPP Trackers3
DC Inputs6
ConnectorsMC4

Mechanical & Environmental Data

Dimensions (W x H x D)480 x 590 x 200 mm
Weight40.0 kg
Protection ClassIP65
Cooling MethodFan
DisplayLCD, LED
InterfaceRS 485, WLAN

Operating Conditions

Operating Temperature-30 ~ +60 ℃
Humidity0-100 %
Frequency50, 60 Hz
Max Altitude3000 m
Transformer TypeTransformerless
Power Consumption (Night)1 W

Similar Products

Product FAQ

What size solar array can the GoodWe GW25K-MT handle?

The GoodWe GW25K-MT has a nominal AC output of 25kW with a maximum efficiency of 98.7%. It is typically paired with a solar array of 30–33kW DC for optimal energy harvest.

Is the GoodWe GW25K-MT a hybrid inverter?

The GoodWe GW25K-MT is a on-grid inverter. To add battery storage, you would need a separate AC-coupled battery inverter or upgrade to a hybrid model.

Does the GoodWe GW25K-MT have WiFi monitoring?

Most GoodWe inverters come with or support optional WiFi/Ethernet dongles. This allows you to track your solar production and battery status via a mobile app or web portal in real-time.

How many MPPT trackers does the GoodWe GW25K-MT have?

This inverter features 3 independent MPPT trackers with a maximum DC input voltage of 1100V. Multiple trackers allow panels on different roof faces or orientations to operate independently for maximum yield.

Is the GoodWe GW25K-MT a three-phase inverter?

Yes, this is a three-phase inverter. Three-phase inverters are ideal for larger homes, commercial systems, or regions with three-phase grid connections.
