Luxpower • LXP 3-6K Hybrid

LXP 4.6K Hybrid

Region:China
Region shows where the seller or factory is located. Most ship globally, and all listed suppliers should be able to ship to your current location.
4.6kW
Nominal AC Power
97.3%
Max Efficiency
455 x 565
Dimensions (mm)
Size Your System Find Installer

Ideal Use Case

The Luxpower LXP 4.6K Hybrid is tailored for specific solar energy needs. This inverter is an excellent choice if you:

Have a 4.6 kW residential PV system
Need 2 independent MPPT trackers for different roof orientations
Prioritize high efficiency performance
Want to add battery storage now or in the future
Operate in extremely cold climates
Want remote monitoring and control capabilities

Don’t guess your solar setup — calculate it first!

Take our Solar Quiz to get a personalized recommendation for panels, inverter, battery capacity, and system size — before you spend money on the wrong setup.

Run Technical Sizing

AC Output Data

Nominal AC Power4.6 kW
Max Efficiency97.3 %
Euro Efficiency97 %
Max AC Current25 A
Rated AC Current0 A
Number of Feed-in Phases0
THD (Total Harmonic Distortion)3 %

DC Input Data

MPP Voltage Range120~500 V
Max DC Voltage550 V
Min DC Voltage to Start140 V
Max DC Current25 A
Number of MPP Trackers2
DC Inputs0
ConnectorsMC4

Mechanical & Environmental Data

Dimensions (W x H x D)455 x 565 x 181 mm
Weight20.0 kg
Protection ClassIP65, NEMA 4X
Cooling MethodNatural
DisplayLCD
InterfaceRS 485, Ethernet, WLAN

Operating Conditions

Operating Temperature-25 ~ +60 ℃
Humidity0-95 %
Frequency45-65 Hz
Max Altitude2000 m
Transformer TypeTransformerless
Power Consumption (Night)5 W

Similar Products

Product FAQ

What size solar array can the Luxpower LXP 4.6K Hybrid handle?

The Luxpower LXP 4.6K Hybrid has a nominal AC output of 4.6kW with a maximum efficiency of 97.3%. It is typically paired with a solar array of 6–6kW DC for optimal energy harvest.

Is the Luxpower LXP 4.6K Hybrid a hybrid inverter?

Yes, the Luxpower LXP 4.6K Hybrid is a hybrid inverter that supports direct battery connection for energy storage and backup power.

Does the Luxpower LXP 4.6K Hybrid have WiFi monitoring?

Most Luxpower inverters come with or support optional WiFi/Ethernet dongles. This allows you to track your solar production and battery status via a mobile app or web portal in real-time.

How many MPPT trackers does the Luxpower LXP 4.6K Hybrid have?

This inverter features 2 independent MPPT trackers with a maximum DC input voltage of 550V. Multiple trackers allow panels on different roof faces or orientations to operate independently for maximum yield.
