MonocrystallineBifacialTOPConN-type
BYD Solar undefined MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555

BYD Solar • auro p mltk 36-530-555w

MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555530W

BifacialTOPConN-type
Region:China
Region shows where the seller or factory is located. Most ship globally, and all listed suppliers should be able to ship to your current location.
530W
Power Output
20.52%
Efficiency
2278 x 1134
Dimensions (mm)
12 Yrs
Product Warranty
Find Installer

Key Features

  • Bifacial design
  • Double-sided power generation
  • Power gain up to 5%~25%
  • Excellent low-light performance
  • Better low-light power generation performance in low radiation environment such as haze and cloudy days
  • Using 182mm size Mono wafer
  • Module power output up to 555W
  • High power output
  • High compatibility
  • Excellent system compatibility
  • Adapt to mainstream inverter and tracker
  • Wide applicability
  • Harsh environments
  • Wider range of application
  • Low LCOE(Levelized Cost of Energy)
  • The cost of BOS reduced by 1.48%
  • LCOE reduced by 1.27%
  • Adopt high-strength aluminum alloy frame
  • Mechanical performance up to 5400 Pa positive load and 2400 Panegative load
  • Higher mechanical load capacity
  • Peak power temperature coefficient
  • Excellent power generation performance in high temperature environment
  • Low temperature coefficient NH3
  • LCOE
  • Comprehensive product certification
  • IEC61215-1(ed.1)
  • IEC61215-1-1(ed.1)
  • IEC61215-2(ed.1)
  • IEC61730-1(ed.2)
  • IEC61730-2(ed.1)
  • UL 61730-1 1 Edition st
  • UL 61730-2 1 Edition st
  • Mono Bifacial Half Cell Module
  • 530-555W MLTK-36
  • Linear power warranty Industry Standard

BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555 Panels: What Your System Looks Like

Based on a standard 10kW residential installation

10kW System Size
19 Panels
Estimated Roof Area
527 sq.ft. (49 m²)
Avg. Yearly Production
11,500 kWh
Generate Professional Technical Report & ROI

Electrical Data (STC)

Maximum Power (Pmax)530 W
Module Efficiency20.52 %
Voltage at Pmax (Vmp)41.61 V
Current at Pmax (Imp)12.74 A
Open Circuit Voltage (Voc)49.12 V
Short Circuit Current (Isc)13.45 A

Mechanical Data

Dimensions2278 x 1134 x 35 mm
Weight27.0 kg
Cell TypeMonocrystalline
Number of Cells144
Front Glass3.2 mm
FrameAnodized Aluminium

Temperature Ratings

Temperature Coefficient of Pmax-0.332 %/°C
Temperature Coefficient of Voc-0.332 %/°C
Temperature Coefficient of Isc-0.252 %/°C
Operating Temperature Range-40 - 85 °C

Similar Products

1134 x 2278 mm
Roof Fit Tool

Will These Panels Fit Your Roof?

Don’t guess your solar potential. Our Roof Layout Designer uses the exact dimensions of the BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555 (530W modules) to map out your system. Visually plan your array to see exactly how many modules your roof can support based on its specific footprint.

Precision Layout Preview: See exactly how the 530W modules sit on your roof.
Accurate Technical Spacing: Factors in real-world gaps and mounting rails.
Instant System Sizing: Automatically calculates total kW output for this specific panel.
Optimization Tips: Suggestions to maximize your roof’s energy density.
Map This Panel on My Roof

Ideal Use Case

The BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555 is designed for specific solar energy applications. This panel is an excellent choice if you:

Want high-power 530W panels for better roof utilization
Prioritize high efficiency performance
Seek cutting-edge technology with superior efficiency
Install on commercial buildings with ample roof space
Install in hot climates (low temperature coefficient)
Install commercial or utility-scale systems

Don’t guess your solar setup — calculate it first!

Take our Solar Quiz to get a personalized recommendation for panels, inverter, battery capacity, and system size — before you spend money on the wrong setup.

Run Technical Sizing

Product FAQ

How many BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555 panels do I need for my home?

The number of panels depends on your energy consumption and roof area. At 530W per panel, a typical 10kW residential system requires about 19 modules. Use our Solar Roof Calculator to get a precise layout based on your actual roof dimensions.

What is the efficiency of BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555?

This panel has an efficiency of 20.52%, using Bifacial, TOPCon, N-type cell technology. Higher efficiency means more electricity per square meter, which is especially valuable when roof space is limited.

Can I get more power from the bifacial BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555?

Yes. Since this is a Bifacial module, it can capture sunlight from both sides. Depending on the reflectivity (albedo) of your roof surface, you can see a gain of 5% to 25% in total energy yield.

What are the dimensions of the BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555?

The module dimensions are 2278mm × 1134mm × 35mm. Always account for these measurements plus fire setbacks and mounting clearances when planning your solar layout.

Is BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555 compatible with standard inverters?

Yes, these panels work with most string and hybrid inverters. However, you must check the Voc (Open Circuit Voltage) and Imp (Current at Max Power) against your inverter's MPPT specs.

What warranty does the BYD Solar MLTK-36 530 MLTK-36 535 MLTK-36 540 MLTK-36 545 MLTK-36 550 MLTK-36 555 come with?

This panel includes a 12-year product warranty from BYD Solar. Solar panels typically degrade about 0.4–0.5% per year, meaning this module should retain over 87% of its original output after 30 years.
