MonocrystallinePERC
Sunman Energy undefined SMF520J-12X12UW

Sunman Energy • earc smf520j 12x12uw

SMF520J-12X12UW520W

PERC
Region:China
Region shows where the seller or factory is located. Most ship globally, and all listed suppliers should be able to ship to your current location.
520W
Power Output
19.34%
Efficiency
2246 x 1197
Dimensions (mm)
12 Yrs
Product Warranty
Find Installer

Key Features

  • 144 Half Cell Monocrystalline Module
  • Ultra-light: Glass free module weighs 7.2 kg, 70% lighter than conventional glass modules.
  • Fast-Installation: Through “Quick-Bonding” installation requires no penetration, reduces time on roof and saves installation costs.
  • Safety: Integration with underlying installation surface, ensuring the waterproof performance and safety performance of the roof.
  • Durable: eArc is the first glassless module to pass the same durability tests as conventional glass modules, including IEC 61215:2021, IEC 61730:2023 and UL61730 (USA). eArc has also passed PID, salt mist level 8 tests.

Sunman Energy SMF520J-12X12UW Panels: What Your System Looks Like

Based on a standard 10kW residential installation

10kW System Size
20 Panels
Estimated Roof Area
581 sq.ft. (54 m²)
Avg. Yearly Production
11,500 kWh
Generate Professional Technical Report & ROI

Electrical Data (STC)

Maximum Power (Pmax)520 W
Module Efficiency19.34 %
Voltage at Pmax (Vmp)42.2 V
Current at Pmax (Imp)12.31 A
Open Circuit Voltage (Voc)49.54 V
Short Circuit Current (Isc)13.5 A

Mechanical Data

Dimensions2246 x 1197 x 2 mm
Weight7.2 kg
Cell TypeMonocrystalline
Number of Cells144
Front Glass0
FrameFrameless

Temperature Ratings

Temperature Coefficient of Pmax-0.3 %/°C
Temperature Coefficient of Voc-0.3 %/°C
Temperature Coefficient of Isc0.02 %/°C
Operating Temperature Range-40 - 85 °C

Similar Products

1197 x 2246 mm
Roof Fit Tool

Will These Panels Fit Your Roof?

Don’t guess your solar potential. Our Roof Layout Designer uses the exact dimensions of the Sunman Energy SMF520J-12X12UW (520W modules) to map out your system. Visually plan your array to see exactly how many modules your roof can support based on its specific footprint.

Precision Layout Preview: See exactly how the 520W modules sit on your roof.
Accurate Technical Spacing: Factors in real-world gaps and mounting rails.
Instant System Sizing: Automatically calculates total kW output for this specific panel.
Optimization Tips: Suggestions to maximize your roof’s energy density.
Map This Panel on My Roof

Ideal Use Case

The Sunman Energy SMF520J-12X12UW is designed for specific solar energy applications. This panel is an excellent choice if you:

Want high-power 520W panels for better roof utilization
Balance efficiency with cost-effectiveness
Want proven monocrystalline technology for better performance
Install on commercial buildings with ample roof space
Install in hot climates (low temperature coefficient)
Install commercial or utility-scale systems

Don’t guess your solar setup — calculate it first!

Take our Solar Quiz to get a personalized recommendation for panels, inverter, battery capacity, and system size — before you spend money on the wrong setup.

Run Technical Sizing

Product FAQ

How many Sunman Energy SMF520J-12X12UW panels do I need for my home?

The number of panels depends on your energy consumption and roof area. At 520W per panel, a typical 10kW residential system requires about 20 modules. Use our Solar Roof Calculator to get a precise layout based on your actual roof dimensions.

What is the efficiency of Sunman Energy SMF520J-12X12UW?

This panel has an efficiency of 19.34%, using PERC cell technology. Higher efficiency means more electricity per square meter, which is especially valuable when roof space is limited.

What are the dimensions of the Sunman Energy SMF520J-12X12UW?

The module dimensions are 2246mm × 1197mm × 2mm. Always account for these measurements plus fire setbacks and mounting clearances when planning your solar layout.

Is Sunman Energy SMF520J-12X12UW compatible with standard inverters?

Yes, these panels work with most string and hybrid inverters. However, you must check the Voc (Open Circuit Voltage) and Imp (Current at Max Power) against your inverter's MPPT specs.

What warranty does the Sunman Energy SMF520J-12X12UW come with?

This panel includes a 12-year product warranty from Sunman Energy. Solar panels typically degrade about 0.4–0.5% per year, meaning this module should retain over 87% of its original output after 30 years.
