MonocrystallineBifacialN-type
Sunman Energy undefined SMF150M-6X05DB

Sunman Energy • sunman earc smf150m 6x05db

SMF150M-6X05DB150W

BifacialN-type
Region:Germany
Region shows where the seller or factory is located. Most ship globally, and all listed suppliers should be able to ship to your current location.
150W
Power Output
17.6%
Efficiency
1023 x 889
Dimensions (mm)
12 Yrs
Product Warranty
Find Installer

Key Features

  • Ultra-light: Glass free module weighs 2.6 kg, 70% lighter than conventional glass module.
  • Aesthetic: Seamless integration with underlying installation surface.

Sunman Energy SMF150M-6X05DB Panels: What Your System Looks Like

Based on a standard 10kW residential installation

10kW System Size
67 Panels
Estimated Roof Area
657 sq.ft. (61 m²)
Avg. Yearly Production
11,500 kWh
Generate Professional Technical Report & ROI

Electrical Data (STC)

Maximum Power (Pmax)150 W
Module Efficiency17.6 %
Voltage at Pmax (Vmp)18.7 V
Current at Pmax (Imp)8.14 A
Open Circuit Voltage (Voc)22.7 V
Short Circuit Current (Isc)8.54 A

Mechanical Data

Dimensions1023 x 889 x 2 mm
Weight2.6 kg
Cell TypeMonocrystalline
Number of Cells30
Front Glass0
FrameFrameless

Temperature Ratings

Temperature Coefficient of Pmax-0.38 %/°C
Temperature Coefficient of Voc-0.29 %/°C
Temperature Coefficient of Isc0.044 %/°C
Operating Temperature Range-40 - 85 °C

Similar Products

889 x 1023 mm
Roof Fit Tool

Will These Panels Fit Your Roof?

Don’t guess your solar potential. Our Roof Layout Designer uses the exact dimensions of the Sunman Energy SMF150M-6X05DB (150W modules) to map out your system. Visually plan your array to see exactly how many modules your roof can support based on its specific footprint.

Precision Layout Preview: See exactly how the 150W modules sit on your roof.
Accurate Technical Spacing: Factors in real-world gaps and mounting rails.
Instant System Sizing: Automatically calculates total kW output for this specific panel.
Optimization Tips: Suggestions to maximize your roof’s energy density.
Map This Panel on My Roof

Ideal Use Case

The Sunman Energy SMF150M-6X05DB is designed for specific solar energy applications. This panel is an excellent choice if you:

Have limited roof space (150W compact panels)
Can benefit from ground-reflected light (bifacial design)
Have smaller installation areas or unique roof constraints
Use standard residential panel configurations

Don’t guess your solar setup — calculate it first!

Take our Solar Quiz to get a personalized recommendation for panels, inverter, battery capacity, and system size — before you spend money on the wrong setup.

Run Technical Sizing

Product FAQ

How many Sunman Energy SMF150M-6X05DB panels do I need for my home?

The number of panels depends on your energy consumption and roof area. At 150W per panel, a typical 10kW residential system requires about 67 modules. Use our Solar Roof Calculator to get a precise layout based on your actual roof dimensions.

What is the efficiency of Sunman Energy SMF150M-6X05DB?

This panel has an efficiency of 17.6%, using Bifacial, N-type cell technology. Higher efficiency means more electricity per square meter, which is especially valuable when roof space is limited.

Can I get more power from the bifacial Sunman Energy SMF150M-6X05DB?

Yes. Since this is a Bifacial module, it can capture sunlight from both sides. Depending on the reflectivity (albedo) of your roof surface, you can see a gain of 5% to 25% in total energy yield.

What are the dimensions of the Sunman Energy SMF150M-6X05DB?

The module dimensions are 1023mm × 889mm × 2mm. Always account for these measurements plus fire setbacks and mounting clearances when planning your solar layout.

Is Sunman Energy SMF150M-6X05DB compatible with standard inverters?

Yes, these panels work with most string and hybrid inverters. However, you must check the Voc (Open Circuit Voltage) and Imp (Current at Max Power) against your inverter's MPPT specs.

What warranty does the Sunman Energy SMF150M-6X05DB come with?

This panel includes a 12-year product warranty from Sunman Energy. Solar panels typically degrade about 0.4–0.5% per year, meaning this module should retain over 87% of its original output after 30 years.
